HP A5800-48G Switch 48x 1Gbit + 4x SFP w/o PSU - JC101A NOB
| MPN | A5800-48G |
|---|---|
| Applicability | Network |
| Manufacturer | Hewlett Packard |
| SKU | 10005829 |
| Product Type | Transceiver |
HP A5800-48G Switch 48x 1Gbit + 4x SFP w/o PSU - JC101A NOB is an enterprise hardware item from Hewlett Packard, suitable for network infrastructure and connectivity projects. This extended description gives a clean overview of the product, key order details and technical specifications for easier compatibility checking.
- Brand: Hewlett Packard
- SKU: 10005829
- Category: Network / Switch / Ethernet Switch
- Stock status: InStock
- Corresponding P/Ns: A5800-48G JC101A
Use the product name, SKU and listed specifications to compare the item with your existing server, storage, workstation or network configuration before ordering.
Technical specifications
| Specification | Details |
|---|---|
| Device type | Ethernet switch |
| Type of construction | Rack-mountable, 2U |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data transfer rate (Ethernet) | 1 Gbps |
| Performance features | |
| ARP | Yes |
| Auto MDI/MDI-X | Yes |
| BGP | Yes |
| CLI | Yes |
| DHCP | Yes |
| Full duplex | Yes |
| HTTP | Yes |
| HTTPS | Yes |
| IGMP | Yes |
| IGMPv2 | Yes |
| IGMPv3 | Yes |
| IPv4 | Yes |
| IS-IS | Yes |
| Managebar | Yes |
| OSPF | Yes |
| OSPFv2 | Yes |
| QoS | Yes |
| RIP v1 | Yes |
| RIP v2 | Yes |
| RMON 1 | Yes |
| RMON 2 | Yes |
| RMON 3 | Yes |
| RMON 9 | Yes |
| SNMPv1 | Yes |
| SNMPv3 | Yes |
| Telnet | Yes |
| VLAN | Yes |
| Product certifications (IEEE) | |
| 802.1D Spanning Tree Protocol (STP) | Yes |
| 802.1Q Tagged VLAN (frame tagging on all ports when VLANs are enabled) | Yes |
| 802.1p Class of Service (CoS) prioritisation | Yes |
| 802.1w Rapid STP (RSTP) | Yes |
| 802.1x port-based authentication | Yes |
| 802.3 10BASE-T Ethernet | Yes |
| 802.3ab 1000BASE-T copper twisted pair Gigabit Ethernet | Yes |
| 802.3ad Link Aggregation Control Protocol | Yes |
| 802.3u 100BASE-TX Fast Ethernet | Yes |
| 802.3x full-duplex flow control | Yes |
| Connections | |
| Network - Ethernet - RJ-45 | 48 |
| Network - Ethernet - SFP | 4 |
| USB | 1 |
| Management - RS-232 - RJ-45 | 1 |
| Modules | |
| Module slots (free) | 2 |
| Note | |
| Special feature | ATTENTION - Power supply unit is not included in the scope of delivery. |
Included in delivery: Item as described incl. Console cable incl. manual incl. Mounting bracket w/o Power cable w/o Power supply unit w/o Additional accessories
Compatibility note: always verify the part number, generation, socket, form factor, controller type, memory type and firmware requirements with your system before purchase.
