Cisco Switch Nexus 93128TX 96x 10GbE RJ45 12x 40GbE QSFP+ 1200W BtF N9K-C93128TX
| MPN | 341-0625-01 |
|---|---|
| Applicability | Network |
| Manufacturer | Cisco |
| SKU | 10010146 |
| Product Type | Transceiver |
CiscoCisco Switch Nexus 93128TX 96x 10GbE RJ45 12x 40GbE QSFP+ 1200W BtF N9K-C93128TX is an enterprise hardware item from CiscoCisco, suitable for network infrastructure and connectivity projects. This extended description gives a clean overview of the product, key order details and technical specifications for easier compatibility checking.
- Brand: Cisco
- SKU: 10010146
- Category: Network / Switch / Ethernet Switch
- Stock status: InStock
- Product family: Cisco Nexus 2000 Fabric Extender| Cisco Nexus 9500
- Corresponding P/Ns: 341-0625-01 800-40684-01 800-40792-02 800-41335-01 N9K-C9300-FAN2-B N9K-C93128TX N9K-M12PQ N9K-PAC-1200W-B
Use the product name, SKU and listed specifications to compare the item with your existing server, storage, workstation or network configuration before ordering.
Technical specifications
| Specification | Details |
|---|---|
| Device type | Ethernet switch |
| Type of construction | Rack-mountable, 1U |
| Data Link Protocol | Gigabit Ethernet, 10GbE, 40GbE |
| Data transfer rate (Ethernet) | 40 Gbps, 10 Gbps, 1 Gbps |
| Flash memory | 64 GB |
| Maximum Power Rating | 853 Watt |
| Number of fans | 3 |
| Power supply units | 2 |
| Max. number of power supply units | 2 |
| Processor | i3- CPU @ 2.50GHz |
| RAM | 16 GB |
| max. power | 2.56 Tbps |
| Airflow | Back to Front (Port-side exhaust) |
| Performance features | |
| ACL | 4000 ingress / 1000 egress |
| CLI | Yes |
| MAC Address Table Size | 96.000 |
| MSTP | Yes |
| Managebar | Yes |
| RSTP | Yes |
| STP | Yes |
| VLAN | 4096 VLANs |
| Connections | |
| Network - Ethernet - QSFP+ | 12 |
| Network - Ethernet 10GBase-T - RJ-45 | 96 |
| USB | 2 |
| Management - Ethernet - RJ-45 | 1 |
| Management - RS-232 - RJ-45 | 1 |
| Modules | |
| Cisco Uplink Module 12p 40G QSFP (N9K-M12PQ) | 1 |
| Note | |
| Special feature | Maximum number of Cisco Nexus 2000 Series Fabric Extenders per switch: 16 |
| Optical defect | May show scratches and signs of use. |
Included in delivery: Item as described incl. Modul incl. Mounting bracket incl. Power cable w/o Rack mount kit w/o Additional accessories
Compatibility note: always verify the part number, generation, socket, form factor, controller type, memory type and firmware requirements with your system before purchase.
