| System BIOS |
| BIOS Type | AMI 32MB Flash ROM |
| Management |
| Software | Supermicro Thin-Agent Service (TAS) |
| Supermicro Server Manager (SSM) |
| SuperCloud Composer® |
| Super Diagnostics Offline (SDO) |
| SuperServer Automation Assistant (SAA) New! |
| Power configurations | ACPI/APM Power Management |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware |
| Secure Boot |
| Secure Firmware Updates |
| Automatic Firmware Recovery |
| Supply Chain Security: Remote Attestation |
| Runtime BMC Protections |
| System Lockdown |
| PC Health Monitoring |
| FAN | Status monitor for speed control |
| Pulse Width Modulated (PWM) fan connectors |
| Fans with tachometer monitoring |
| Temperature | Monitoring for CPU and chassis environment |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory. |
| 8+4 Phase-switching voltage regulator |
| Processor (per Node) |
| CPU | Dual Socket E2 (LGA-4710) |
| Intel® Xeon® 6700/6500 series processors with P-cores or 6700 series processors with E-cores |
| Core Count | P-cores: Up to 86C/172T, Up to 336MB Cache per CPU |
| E-cores: Up to 144C/144T, Up to 108MB Cache per CPU |
| Note | Supports up to 350W TDP CPUs (Liquid Cooled) |
| Supports up to 350W TDP CPUs (Air Cooled)* |
| *Air Cooled CPUs with TDP over 250W only supported under specific conditions. Contact a Supermicro representative for details. |
| Front Panel |
| Buttons | Power On/Off button |
| UID button |
| LED | Power status LED |
| HDD activity LED |
| Network activity LEDs |
| Universal Information (UID) LED |
| Product SKUs |
| Product SKUs | SYS-222BT-DNR |
| Motherboard |
| Motherboard | Super X14DBT-B |
| System Memory (per Node) |
| Memory | View Memory Options |
| Slot Count: 16 DIMM slots |
| Max Memory (1DPC): Up to 4TB 6400MT/s ECC DDR5 RDIMM |
| Memory Voltage | 1.1V |
| On-Board Devices (per Node) |
| Chipset | System on Chip |
| Network Connectivity | View AOC Options |
| Via AIOM |
| View AIOM Options |
| Input / Output (per Node) |
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port |
| USB | 2 USB 3.0 Gen2 Type-A ports(Rear) |
| Video | 1 VGA port |
| Chassis |
| Form Factor | 2U Rackmount |
| Model | CSE-217BD2-R2K22P |
| Dimensions and Weight |
| Height | 3.47' (88 mm) |
| Width | 17.68' (449 mm) |
| Depth | 28.75' (730 mm) |
| Package | 9.76' (H) x 24.65' (W) x 45.28' (D) |
| Weight | Gross Weight: 80.7 lbs (36.6 kg) |
| Net Weight: 55.1 lbs (25 kg) |
| Available Color | Black front & silver body |
| Expansion Slots (per Node) |
| PCI-Express (PCIe) Configuration |
| Drive Bays / Storage (per Node) |
| Drive Bays Configuration | View NVMe Options |
| 6 front hot-swap 2.5' PCIe 5.0 NVMe drive bays |
| Default: Total 12 bays 12 front hot-swap 2.5' PCIe 5.0 NVMe drive bays |
| 12 front hot-swap 2.5' PCIe 5.0 NVMe drive bays |
| Option A: Total 6 bays 6 front hot-swap 2.5' PCIe 5.0 NVMe drive bays |
| M.2 | View M.2 Options |
| 2 M.2 PCIe 5.0 x4 NVMe slots (M-key 22110(default), VROC required for RAID) |
| System Cooling |
| Fans | 4x 16.5K RPM Heavy Duty 80x80x38mm Fan(s) |
| 4x 16k RPM Counter Rotating 80x80x56mm Fan(s) (optional) |
| Air Shroud | 2 Air Shrouds |
| Liquid Cooling | Direct to Chip (D2C) Cold Plate (optional) |
| Operating Environment |
| ROHS | RoHS Compliant |
| Environmental Spec. | Non-operating Temperature: -30°C to 60°C (-22°F to 140°F) |
| Operating Relative Humidity: 8% to 80% (non-condensing) |
| Non-operating Relative Humidity: 8% to 90% (non-condensing) |
| Operating Temperature: 10°C to 35°C (50°F to 95°F) |
