| Main Specifications |
| Device Type | 800G Ethernet Switch |
| Form Factor | 2 RU |
| Dimensions (WxDxH) | 438.4 x 650 x 87.4mm |
| Weight | 26kg |
| Key Features | AC Power Supply with Regular Airflow (back to front) |
| Processor |
| Onboard CPU Engine | Intel Xeon-D x86 CPU, 8C at 2.3GHz |
| 32GB DDR4 |
| 128GB SSD |
| Expansion / Connectivity |
| Expansion / Connectivity | 64x 800G OSFP Ports |
| 2x 25G SFP28 ports |
| 1x RJ45 console and 1xOOB Ethernet management ports |
| 1x USB 2.0 Type A interface |
| Miscellaneous |
| Compliance | 802.1p QOS/COS, 802.1Q VLAN Tagging, 802.1AB Link Layer Discovery Protocol, 802.3ad Link Aggregation with LACP, 802.3ae 10 Gigabit Ethernet, 802.3-2022 25 Gigabit Ethernet, 802.3cd 50 Gigabit Ethernet, 802.3ba 100 Gigabit Ethernet, 802.3bs 400 and 200 Gigabit Ethernet, 802.3cm 400 Gigabit over multimode fiber, 802.1Qbb PFC 802.1Qaz ETS, 802.1X Network Access Control, 802.3x Flow Control |
| Networking |
| Layer 2 Features | VLAN Auto-state, Interface Hold-Down, LACP Graceful Shutdown, link Tracking, LACP Fast Rate and LACP Fallback, Static LAG, LLDP, UDLD, PVST and RPVST+, MSTP, DHCP snooping, Port Channel Min-Links configuration enhancement |
| Layer 3 Features | DHCP Relay Enhancements, Overlay Interfaces, DHCP Relay Source Interface Selection (e.g. loopback), DHCP Relay over IPv6 Link-Local Interfaces with RFC5549 Routes, DHCP Relay Hop Count Configuration, DHCP Relay Over IPv4 Unnumbered Interfaces, DHCP Relay Option 82, Sub Option 151 VRF Name/ID Option, DHCP Relay Option 82, Sub Option 5 Link-Selection Option RFC3527, Support for Circuit-Id Formats, DHCP Relay Circuit-Id Option, DHCP Relay and DHCP snooping support on the same VLAN, Dynamic BGP Neighbor, IP Fabric over IPv6 underlay RFC5549, IP Helper, Route Leaking across VRFs including Management VRF, BGP Docker Warm Restart, Avoid Netlink for Handling IPv6 Link-Local Address, BFD Optimizations to Support 5x100msec Aggressive Timers in SW, IP SLA (ICMP and TCP tracker), IPv4 Unnumbered Interfaces, RPVST+ over MC-LAG, RPVST+ Scaling to 3500 VLAN Ports, Symmetric Hashing, BFD IS-CLIs, BFD with VRF, VRF support for syslog, VRF support for SSH.in, VRRPv3, VRRP/VRRPv3 over VRF, Management VRF Hardening, OSPFv2, Multi-Site Data Center Interconnect (DCI), RIB/FIB Consistency Checker, Next Hop Group (NHG) Support, RIF Counters for L3 Interfaces, BFD Profile, Route Updates Performance Improvements, Drop Neighbor Entry to Protect CPU from Unknown IP Packets Hitting the CPU, CPU Offload for Neighbor Suppression, CPU Offload for Slowpath ARP Flooding, OSFPv2 GR, Router Advertisement, KLISH/REST/gNMI Support, CLI Commands for RA Retransmission Interval, RADv Disable, RFE-8106 |
| ACL and Flow-Based Services | PBR Enhancements for Service Chaining, ACL-based CoPP, ACL DSCP Map/Remarking, ACL Rate Limiting, Control Plane ACL, Policy-based Routing (IPv4 and IPv6), ACL-based Packet Replication, ACL Consistency Checker |
| Multicast Features / Enhancements | L3 Multicast with PIM operates on L3 interfaces only, IGMP, IGMP Snooping (v1, v2, v3), IPv4 PIM-SSM Support |
| Debuggability / Serviceability features | In-memory Debug Logging, Audit Logging and Syslogs, Command to Return Interfaces to the Default Configuration, Port Mirroring on Port Channel and VLAN |
| QoS | DSCP Marking Preservation for QoS Map Support for Remarking and SVI Port and Priority Shaping |
| Telemetry and Instrumentation | sFlow on Management VRF, BST – Watermarks, Port MAC Security, LLDP-MED |
| Security Features |
| Security Features | RADIUS and TACACS, RADIUS/TACACS Password Obfuscation, NTP Server and NTP Authentication, NTP Prefer Option, LDAP Integration, AAA Authorization support with TACACS+ |
| Software Features |
| Manageability Features | Industry Standard CLI (IS-CLI), REST and gNMI Interfaces via OpenConfig YANG (OC-YANG), Role-Based Access Control (RBAC), RBAC and HAMd Enhancements, SNMP Configuration Traps and OIDs, gNMI Subscription Support for Limited YANG Paths (OnChange, Interval, Once, Poll, Target defined), Bulking support in both REST(YANG patch) and gNMI, Query parameter for REST and filtering support for gNMI, Scalar encoding support for gNMI, Support to Read Service Tag via SNMP, SNMP Trap Enablement on Interface Instead of Global |
| Scalability improvements | Host Table Resource Reservation for Local Hosts |
| L3 VLAN Scale to 4K |
| Warmboot | AI/ML Focused Features, RoCEv2, PFC, ECN, Enhanced DCQCN, Dynamic Load Balancing (DLB), Packet Spraying, Enhanced Hashing and Load Balancing with 100mSec granularity, Rich Congestion and Load Balancing Telemetry |
