| Main Specifications |
| Device Type | Motherboard |
| Form Factor | Micro-ATX |
| Dimensions (WxDxH) | 9.6' x 9.6' (24.384cm x 24.384cm) |
| Processor |
| Compatible Processors | AMD EPYC 4004 / 4005 or AMD Ryzen 7000 / 9000 Series Processors |
| Compatible Socket | Single processor |
| Cache/Core | Up to 16C/32T |
| System Memory |
| Memory Type | Slot Count: 4 DIMM Slots, Max Memory (1DPC): Up to 192GB 5600MT/s ECC/non-ECC DDR5 UDIMM |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors, Detects double-bit errors (using ECC memory) |
| On-Board Devices |
| Chipset | B650 |
| SATA RAID | 4 SATA (6Gbps), RAID 0/1/10 support |
| IPMI | ASPEED AST2600 BMC |
| Network Controllers | Dual LAN with Intel i210 Gigabit Ethernet Controller, Single LAN with ASPEED AST2600 BMC, Dedicated LAN for IPMI |
| Audio | ALC 888S HD Audio |
| TPM | 1 TPM 2.0 header |
| Input / Output |
| USB(s) | 2 USB 3.2 Gen1 port(s) (Header), 3 USB 3.2 Gen2 Type-A port(s) (Rear), 1 USB 3.2 Gen2x2 Type-C port(s) (Rear), 2 USB 3.2 Gen2 Type-C port(s) (Rear), 1 USB 2 port(s) (Header) |
| Video Output | 1 HDMI 2 port, 1 Display Port port, 2 VGA Type-C 3.2 Gen2 port(s) (Rear) |
| Serial Port / Headers | 1 COM port(s) (header) |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 PCIe 4.0 x4 slot, 2 PCIe 5.0 x16 slots |
| M.2 | 2 M.2 PCIe 5.0 x4 slots (M-key 2280/22110) |
| System BIOS |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| BIOS Features | ACPI 6.4, Plug and Play (PnP), SMBIOS 3.5 or later, UEFI 2.8, USB Keyboard support |
| Software |
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), Plug-ins for 3rd Party Software, IPMI Utilities, SAA (limited support) |
| Management |
| Power Configurations | Power-on mode control for AC power loss recovery, Power button override mechanism, S3/S4/S5 |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| PC Health Monitoring |
| Voltage | +12V,+3.3V,+5V,+5V standby,3.3V standby,CPU temperature,CPU thermal trip support,Memory temperature,PCH temperature,System temperature |
| FAN | 7x 4-pin fan headers (up to 7 fans) |
| Parts List |
| I/O Shield | 1x MCP-260-00185-0B |
| I/O Cables | 2x CBL-0044L |
