| Main Specifications |
| Device Type | Motherboard |
| Form Factor | Proprietary |
| Dimensions (WxDxH) | 18.23' x 6.3' (46.3cm x 16cm) |
| Processor |
| Compatible Processors | Intel Xeon 6700/6500 series processors with P-cores or 6700 series processors with E-cores |
| Compatible Socket | Dual Socket E2 (LGA-4710), Up to 350W TDP |
| Core Count | Up to 144C |
| System Memory |
| Memory Capacity | Slot Count: 16 DIMM Slots, Max Memory (1DPC): Up to 4TB 6400MT/s ECC DDR5 RDIMM |
| DIMM Sizes | MRDIMM (P-core only):32GB, 64GB |
| RDIMM:16GB, 32GB, 64GB, 128GB, 256GB |
| Memory Voltage | 1.1V |
| Error Detection | Corrects single-bit errors, Detects double-bit errors (using ECC memory) |
| On-Board Devices |
| Network Controllers | Dual LAN with Intel Ethernet Controller E810-XXVAM2 |
| Input / Output |
| USB(s) | 1 USB 3.1 Gen1 Type-A port(s) |
| TPM | 1 TPM onboard |
| Expansion / Connectivity |
| Expansion Slots Total (Free) | 1 PCIe 5.0 x16 AIOM slot |
| 2 PCIe 5.0 x8 via MCIO Connector slots |
| M.2 | 1 M.2 PCIe 5.0 x4 slot (M-key 2280) |
| System BIOS |
| BIOS Type | AMI 64MB UEFI |
| BIOS Features | ACPI 6.5, SMBIOS 3.7 or later, UEFI 2.9 |
| Management |
| Software | SuperCloud Composer, Supermicro Server Manager (SSM), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New, Plug-ins for 3rd Party Software |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| PC Health Monitoring |
| Voltage | +12V,+3.3V,+5V,+5V standby,Monitors CPU voltages,Supports system management utility,System level control,VBAT |
| LED | CPU/system overheat LED, UID/remote UID LED |
| Temperature | CPU thermal trip support, Monitoring for CPU and chassis environment, PECI, Thermal monitor 2 (TM2) support |
| FAN | 1x 4-pin fan header (up to 1 fan), Fan speed control |
| Other Features | ACPI power management Chassis intrusion detection Control of power-on for recovery from AC power loss M.2 NGFF connector UID |
