| Product SKUs |
| Product SKUs | AS -8125GS-TNMR2 |
| Motherboard |
| Motherboard |
| Processor |
| CPU | Dual Socket SP5 |
| AMD EPYC™ 9004 Series Processors |
| Note | Supports up to 400W TDP CPUs (Air Cooled) |
| GPU |
| Max GPU Count | Up to 8 onboard GPU(s) |
| Supported GPU | View GPU Options |
| AMD: Instinct MI300X Accelerators |
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect |
| GPU-GPU Interconnect | AMD Infinity Fabric™ Link |
| System Memory |
| Memory | View Memory Options |
| Slot Count: 24 DIMM slots |
| Max Memory (1DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM/LRDIMM |
| Memory Voltage | 1.1V |
| On-Board Devices |
| Chipset | AMD SP5 |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Network Connectivity | View AOC Options |
| Input / Output |
| Video | 1 VGA port(s) |
| System BIOS |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Management |
| Software | KVM with dedicated LAN |
| Redfish API |
| SuperDoctor® 5 |
| IPMI 2.0 |
| Supermicro Update Manager (SUM) |
| Supermicro Server Manager (SSM) |
| Super Diagnostics Offline |
| Power configurations | Power-on mode for AC power recovery |
| ACPI Power Management |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware |
| Secure Boot |
| Secure Firmware Updates |
| Automatic Firmware Recovery |
| Supply Chain Security: Remote Attestation |
| Runtime BMC Protections |
| System Lockdown |
| PC Health Monitoring |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory |
| 7 +1 Phase-switching voltage regulator |
| FAN | Status monitor for speed control |
| Fans with tachometer monitoring |
| Temperature | Monitoring for CPU and chassis environment |
| Thermal Control for fan connectors |
| Chassis |
| Form Factor | 8U Rackmount |
| Model | CSE-GP801TS |
| Dimensions and Weight |
| Height | 14' (355.6 mm) |
| Width | 17.2' (437 mm) |
| Depth | 33.2' (843.28 mm) |
| Package | 29.5' (H) x 27.5' (W) x 51.2' (D) |
| Weight | Gross Weight: 225 lbs (102.1 kg) |
| Net Weight: 166 lbs (75.3 kg) |
| Available Color | Black front & silver body |
| Front Panel |
| LED | Power status LED |
| Network activity LEDs |
| Hard drive activity LED |
| System Overheat & Power Fail LED |
| Buttons | Power On/Off button |
| System Reset button |
| Expansion Slots |
| PCI-Express (PCIe) Configuration |
| Drive Bays / Storage |
| Drive Bays Configuration | View Drive Options |
| 12 front hot-swap 2.5' NVMe drive bay(s) |
| (*NVMe support may require additional storage controller and/or cables, please see the optional parts list for details) |
| Default: Total 18 bay(s) 12 front hot-swap 2.5' NVMe drive bay(s) 2 front hot-swap 2.5' SATA drive bay(s) 4 front hot-swap 2.5' NVMe* drive bay(s) |
| 2 front hot-swap 2.5' SATA drive bay(s) |
| 4 front hot-swap 2.5' NVMe* drive bay(s) |
| M.2 | View M.2 Options |
| 2 M.2 NVMe slot(s) (M-key) |
| System Cooling |
| Fans | N/A |
| Power Supply |
| Dimension (WxHxL) | 106.5 x 82.1 x 245.5 mm |
| +12V | Max: 91.66A / Min: 0A (200Vdc-240Vdc) |
| 12V SB | Max: 3A / Min: 0A |
| AC Input | 2880W: 200-207Vac / 50-60Hz |
| 3000W: 0240Vdc / 50-60Hz (for CQC only) |
| 3000W: 207-240Vac / 50-60Hz |
| Output Type | Backplanes (gold finger) |
| Operating Environment |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) |
