| Product SKUs |
| Product SKUs | AS -1115S-FDWTRT |
| Motherboard |
| Motherboard | Super H13SVW-NT |
| Processor |
| CPU | Single processor(s) |
| AMD EPYC™ 8004 Series Processor |
| Core Count | Up to 64C/128T |
| Note | Supports up to 200W TDP CPUs (Air Cooled) |
| GPU |
| Max GPU Count | Up to 1 single-width GPU(s) |
| Supported GPU | NVIDIANVIDIA A30 PCIe: A2 |
| View GPU Options |
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect |
| System Memory |
| Memory | Slot Count: 6 DIMM slots |
| Max Memory (2DPC): Up to 576GB 4800MT/s ECC DDR5 RDIMM |
| View Memory Options |
| On-Board Devices |
| SATA | SATA (6Gbps) |
| NVMe | NVMe, (Optional) |
| Chipset | System on Chip |
| Network Connectivity | 2 RJ45 10GBASE-T with Broadcom® BCM57416 |
| View AOC Options |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Input / Output |
| LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s) |
| 2 RJ45 10 GbE LAN port(s) |
| USB | 4 port(s) |
| Video | 1 VGA port(s) |
| TPM | 1 TPM header |
| System BIOS |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| BIOS Features | ACPI 6.4 SMBIOS 3.5 or later UEFI 2.8 Plug and Play (PnP) USB Keyboard support |
| Management |
| Software | KVM with dedicated LAN |
| Redfish API |
| SuperDoctor® 5 |
| IPMI 2.0 |
| Supermicro Update Manager (SUM) |
| Supermicro Server Manager (SSM) |
| Super Diagnostics Offline |
| Power configurations | 1U 600W Redundant DC48V input w/PMBus power supply |
| Security |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware |
| Secure Boot |
| Secure Firmware Updates |
| Automatic Firmware Recovery |
| Supply Chain Security: Remote Attestation |
| Runtime BMC Protections |
| System Lockdown |
| PC Health Monitoring |
| FAN | Status monitor for speed control |
| Pulse Width Modulated (PWM) fan connectors |
| Fans with tachometer monitoring |
| Temperature | Monitoring for CPU and chassis environment |
| Thermal Control for fan connectors |
| Voltage | System temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support |
| CPU | Monitors for CPU thermal trip, Chipset Voltages, Memory |
| Chassis |
| Form Factor | 1U Rackmount |
| Model | CSE-515B-R000WNP |
| Dimensions and Weight |
| Height | 1.7' (44.5 mm) |
| Width | 17.2' (436.88 mm) |
| Depth | 16.9' (429.3 mm) |
| Package | 8' (H) x 27' (W) x 24' (D) |
| Weight | Gross Weight: 15 lbs (6.8 kg) |
| Net Weight: 10 lbs (4.54 kg) |
| Available Color | Silver |
| Front Panel |
| LED | LAN1 activity |
| LAN2 activity |
| Power status |
| Buttons | Power On/Off |
| Expansion Slots |
| PCI-Express (PCIe) Configuration |
| Drive Bays / Storage |
| Drive Bays Configuration | Default: Total 2 bay(s) 2 internal fixed 2.5' NVMe/SAS/SATA drive bay(s) |
| 2 internal fixed 2.5' NVMe/SAS/SATA drive bay(s) |
| View Drive Options |
| M.2 | 2 M.2 PCIe 3.0 x4 NVMe slot(s) (M-key 2280/22110) |
| View M.2 Options |
| System Cooling |
| Fans | 6 Heavy duty counter-rotating 4cm Fan(s) |
| Power Supply |
| Dimension (WxHxL) | 54.5 x 40 x 220 mm |
| 5V SB | Max: 3A / Min: 0A |
| Output Type | Backplanes (gold finger) |
| Operating Environment |
| ROHS | RoHS Compliant |
| Environmental Spec. | Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) |
