Cisco Switch Nexus 9372PX 48x 10GbE 4x QSFP+ 40GbE - N9K-C9372PX
| MPN | 800-43113-02 |
|---|---|
| Applicability | Network |
| Manufacturer | Cisco |
| SKU | 10007515 |
| Product Type | Transceiver |
CiscoCisco Switch Nexus 9372PX 48x 10GbE 4x QSFP+ 40GbE - N9K-C9372PX is an enterprise hardware item from CiscoCisco, suitable for enterprise IT infrastructure projects. This extended description gives a clean overview of the product, key order details and technical specifications for easier compatibility checking.
- Brand: Cisco
- SKU: 10007515
- Stock status: InStock
- Product family: Cisco Nexus 2000 Fabric Extender| Cisco Nexus 7000| Cisco Nexus 9500
- Corresponding P/Ns: 800-43113-02 N9K-C9372PX Nexus 9000 Nexus 9300
Use the product name, SKU and listed specifications to compare the item with your existing server, storage, workstation or network configuration before ordering.
Technical specifications
| Specification | Details |
|---|---|
| Device type | Ethernet switch |
| Type of construction | Rack-mountable, 1U |
| Data Link Protocol | Gigabit Ethernet, 10GbE, 40GbE |
| Data transfer rate (Ethernet) | 40 Gbps, 10 Gbps, 1 Gbps |
| Flash memory (MB) | 52496 |
| Maximum Power Rating | 537 watts |
| Power supply units | 2 |
| Processor | i3- CPU @ 2.50GHz |
| RAM (MB) | 16402 |
| max. power | 1.44 Tbps |
| Airflow | Rear to Front |
| Performance features | |
| ACL | 4000 ingress / 1000 egress |
| CLI | Yes |
| MAC Address Table Size | 96.000 |
| MSTP | Yes |
| Managebar | Yes |
| RSTP | Yes |
| STP | Yes |
| VLAN | 4096 VLANs |
| Connections | |
| Network - Ethernet - QSFP+ | 6 |
| Network - Ethernet - SFP+ | 48 |
| USB | 2 |
| Management - Ethernet - RJ-45 | 1 |
| Management - RS-232 - RJ-45 | 1 |
| Note | |
| Special feature | Nexus 9372PX does not support IP-based endpoint group (EPG) classification in ACI mode. |
Included in delivery: Item as described incl. Mounting bracket incl. Power cable w/o Additional accessories
Compatibility note: always verify the part number, generation, socket, form factor, controller type, memory type and firmware requirements with your system before purchase.
