Cisco Switch Catalyst 3750X 48x 1GbE PoE+ 4x SFP 1x PSU - WS-C3750X-48PF-S
| MPN | 341-0354-01 |
|---|---|
| Applicability | Network |
| Manufacturer | Cisco |
| SKU | 10010106 |
| Product Type | Transceiver |
CiscoCisco Switch Catalyst 3750X 48x 1GbE PoE+ 4x SFP 1x PSU - WS-C3750X-48PF-S is an enterprise hardware item from CiscoCisco, suitable for enterprise IT infrastructure projects. This extended description gives a clean overview of the product, key order details and technical specifications for easier compatibility checking.
- Brand: Cisco
- SKU: 10010106
- Stock status: InStock
- Corresponding P/Ns: 341-0354-01 73-12298-04 C3KX-FAN-23CFM C3KX-NM-1G C3KX-PWR-1100WAC WS-C3750X-48PF-S
Use the product name, SKU and listed specifications to compare the item with your existing server, storage, workstation or network configuration before ordering.
Technical specifications
| Specification | Details |
|---|---|
| Device type | Ethernet switch |
| Type of construction | Rack-mountable, 1U |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Data transfer rate (Ethernet) | 1 Gbps |
| Flash memory | 64 MB |
| Maximum Power Rating | 1100 Watt |
| Number of fans | 2 |
| Power supply units | 1 |
| Max. number of power supply units | 2 |
| PoE Power | 800 Watt |
| RAM | 256 MB |
| max. power | 160 Gbps |
| Airflow | Front to Rear |
| Performance features | |
| ACL | Yes |
| Auto MDI/MDI-X | Yes |
| CLI | Yes |
| DHCP | Yes |
| Managebar | Yes |
| PoE | Yes |
| QoS | Yes |
| RMON 1 | Yes |
| RMON 2 | Yes |
| RMON 3 | Yes |
| RMON 9 | Yes |
| RSTP | Yes |
| SNMPv1 | Yes |
| SNMPv2c | Yes |
| SNMPv3 | Yes |
| SSH | Yes |
| TFTP | Yes |
| Telnet | Yes |
| VLAN | 4000 IDs / 1005 VLANs |
| Connections | |
| Network - Ethernet - SFP | 4 |
| Network - PoE+ - RJ-45 | 48 |
| Stacking port | 2 |
| USB | 1 |
| Management - Ethernet - RJ-45 | 1 |
| Management - RS-232 - Mini-USB | 1 |
| Management - RS-232 - RJ-45 | 1 |
| Network functions | |
| Jumbo frame size (in byte) | 9216 |
| Modules | |
| Cisco 4x 1GbE SFP Network Module (C3KX-NM-1G) | 1 |
| Installed licences | |
| IP Base feature set | Yes |
| Note | |
| Special feature | ATTENTION - Mains cables are not included in the scope of delivery. |
| Optical defect | May show scratches and signs of use. |
Included in delivery: Item as described incl. Modules incl. Mounting bracket w/o Power cable w/o Additional accessories
Compatibility note: always verify the part number, generation, socket, form factor, controller type, memory type and firmware requirements with your system before purchase.
