APC USV Smart-UPS 5000VA/4500W 1P+N+PE - 4x C19 6x C13 3U - SRT5KRMXLI Batteries new
| MPN | AP9537SUM |
|---|---|
| Applicability | Power |
| Manufacturer | APC |
| SKU | 30006878 |
| Product Type | Rack Accessory |
APC USV Smart-UPS 5000VA/4500W 1P+N+PE - 4x C19 6x C13 3U - SRT5KRMXLI Batteries new is an enterprise hardware item from APC, suitable for enterprise IT infrastructure projects. This extended description gives a clean overview of the product, key order details and technical specifications for easier compatibility checking.
- Brand: APC
- SKU: 30006878
- Stock status: InStock
- Product family: APC Smart UPS SRT 192V Rack Battery Pack (SRT192RMBP)
- Corresponding P/Ns: AP9537SUM APCRBC140 SRT5KRMXLI
Use the product name, SKU and listed specifications to compare the item with your existing server, storage, workstation or network configuration before ordering.
Technical specifications
| Specification | Details |
|---|---|
| Category | UPS |
| Input voltage | 220 - 240 VAC |
| Output voltage | 220 - 240 VAC |
| Frequency limit (mains operation) | 50-60 Hz |
| Battery type | Maintenance-free, sealed lead-acid battery with suspended electrolyte, leak-proof |
| Battery status | The device is supplied with new batteries. |
| Max. Amperage | 16 A |
| Max. Current per output | C13 10A - C19 16A |
| Max. output power | 4500 Watt/5000VA |
| Normal battery life at full load (manufacturer's specification) | 4 minutes (4500 watts) |
| Operating time at half load (manufacturer's specification) | 11.5 minutes (2250 watts) |
| Management | Yes |
| Data transfer rate (Ethernet) | 10 Mbps, 100 Mbps |
| Input connections | |
| ERM connection | 1 |
| IEC 60309 1P+N+PE 6h, 32A | 1 |
| Output connections | |
| IEC 60320 C19 | 4 |
| IEC 60320 C13 | 6 |
| Number of load segments | 2 |
| Interfaces | |
| USB | 1 |
| Management - Ethernet - RJ-45 | 1 |
| Management - RS-232 - 2.5mm jack | 1 |
| Management - RS-232 - RJ-45 | 1 |
| Charging time | |
| Complete charging | 1.5 hours |
| LED status display | |
| Operation | Yes |
| Battery operation | Yes |
| Battery change | Yes |
| Overload | Yes |
| Features | |
| Access via browser | Yes |
| Event log | Yes |
| Password security | Yes |
| Telnet administration | Yes |
| Protocols | |
| HTTP | Yes |
| HTTPS | Yes |
| SSH | Yes |
| SNMPv1 | Yes |
| SNMPv3 | Yes |
Included in delivery: Item as described incl. Batteries incl. Front panel incl. Management Card incl. Rack mounting bracket w/o Power cable w/o Additional accessories
Compatibility note: always verify the part number, generation, socket, form factor, controller type, memory type and firmware requirements with your system before purchase.
